TP-LINK MC211CS-20 Gigabit Single-Mode Media Converter
Effortlessly extend your Gigabit Ethernet network over long distances with the TP-LINK MC211CS-20, a high-performance media converter designed for reliability and simplicity. This device is the perfect solution for connecting your copper-based network to a fiber optic backbone, overcoming the 100-meter distance limitation of traditional UTP cabling. By converting a 1000BASE-T RJ45 Ethernet signal to a 1000BASE-LX/LH single-mode fiber optic signal, the MC211CS-20 allows you to transmit data up to an impressive 20 kilometers (12.4 miles). This makes it ideal for connecting remote workgroups, campus buildings, or industrial sites where long-distance, high-speed connectivity is essential.
Built for robust performance, the MC211CS-20 ensures a stable and secure connection. Single-mode fiber is inherently immune to electromagnetic interference (EMI), providing a cleaner signal and enhanced data integrity in electrically noisy environments. Its simple plug-and-play design means installation is quick and straightforward, with no complex configuration required. The converter can be used as a standalone device or installed into TP-Link´s 19-inch system chassis, offering flexible deployment options for any network infrastructure. Diagnostic LEDs for Power, Link, and Activity status provide at-a-glance monitoring of your network connection.
Key Benefits:
* Extended Network Reach: Drastically extend your Gigabit network connection up to 20 km using cost-effective single-mode fiber optic cable.
* High-Speed Gigabit Performance: Delivers full wire-speed 1000 Mbit/s data transfer rates for both fiber and copper ports, ensuring no performance bottlenecks.
* Enhanced Reliability: Utilizes single-mode fiber, which is immune to electromagnetic interference (EMI), guaranteeing a stable and secure data link in challenging environments.
* Plug-and-Play Installation: Requires no software or configuration. Simply connect the cables and power it on for immediate operation.
* Flexible Deployment: Can be used as a standalone unit or mounted in a TP-LINK 19-inch rackmount chassis for centralized management in larger network setups.
* Cost-Effective Expansion: Provides a budget-friendly way to integrate fiber optics into your existing copper network without replacing your current switches.
Main Features:
* Complies with IEEE 802.3ab (1000Base-T) and IEEE 802.3z (1000Base-LX/LH) standards.
* Provides one SC fiber connector and one RJ45 copper connector.
* Auto-negotiation of 1000Mbps speed and Full-Duplex mode for the TX port.
* Auto MDI/MDI-X support for the RJ45 port, eliminating the need for crossover cables.
* FX port supports hot-swappable functionality.
* Easy-to-view LED indicators for monitoring network activity and status.
* Works at 1310nm wavelength for both transmitting and receiving data.
Power Suppliers:
The device is powered by an external power adapter.
* Input: 100-240V 50/60Hz
* Output: 5V/0.6A
Technical Specifications:
* Standards and Protocols: IEEE 802.3ab, IEEE 802.3z
* Ports: 1x 1000M SC/UPC port, 1x 10/100/1000M RJ45 port (Auto MDI/MDIX)
* Network Media (Copper): 1000BASE-T: UTP category 5, 5e cable
* Network Media (Fiber): 1000BASE-LX/LH: Single-mode Fiber
* Fiber Type: 9/125 µm Single-Mode Fiber
* Wavelength: 1310nm
* Max Fiber Cable Length: 20 km
* LED Indicators: PWR, LINK, ACT
* Dimensions (W*D*H): 3.7 × 2.9 × 1.1 in. (94.5 × 73.0 × 27.0 mm)
