Description

Perfect for riding on rough roads, gravel or dirt, it gives you the smooth-riding performance of tubeless tires and makes it easy to set them up without any hassles. Low rolling resistance and a reduced risk of punctures add up to a better overall riding experience, especially on rugged terrain.
The wheels are engineered for the unique demands of disc brakes, built up with 24 straight-pull spokes, which are stronger than J-bend spokes. So wherever the road goes, and however rough it gets, you´re ready to keep things rolling.
Key benefits:
Purpose-built for riding rough roads, gravel or dirt:
– 23mm wide rim takes tire up to 62mm.
– UST Road Tubeless technology improves comfort and rolling resistance, and reduces the risk of punctures.
– Compatible with all standard retention systems.
Proven performance and reliability at an attainable cost:
– High-quality QRM cartridge bearings.
– Disc-brake-specific, sleeved-style rim technology.
– Straight-pull round spokes, which are stronger than J-bend spokes.
Rolling efficiency and a nimble ride quality:
– Sleeve joint rim minimizes weight.
– Consistent and stable spoke lacing.
– Low-friction hubs.
Specifications:
Compatibility:
– Rear axle: 12mm thru axle, convertible to Quick Release with included adapters
Compatible Adapters and freewheel bodies:
– ID360 Shimano / Sram freewheel body (V3430101 – Delivered on the wheel)
– ID360 XD-R freewheel body (V2580101)
– ID360 Campagnolo freewheel body (V3440101)
– ID360 Shimano / Sram Light freewheel body (V3850101)
– 12×135 rear axle adapters (V2510901)
– 12 to 9mm rear adapter for quick release (V2510801 – Delivered with the wheel)
– 12×142 rear axle adapters (V2510701 – Delivered with the wheel)
– 15mm axle (V2373501) + 15mm fork rest (V2372501)
– 12 to 9mm front adapter for quick release (V2680301 – Delivered with the wheel)
Weight:
– Rear without tyre: 1020 grams
Hubs:
– Auto adjust sealed cartridge bearings (QRM Auto), front and rear
– Freewheel: Instant Drive 360 steel
– Front: Quick release, 12×100 and 15×100 through axle compatible
– Rear: Quick Release, 12×142 and 12×135 compatible
– Front and rear bodies: aluminum
– Axle material: aluminum
Intended Use:
– For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don´t exceed 120kg, bike included
– ASTM CATEGORY 2 : road and offroad with jumps less than 15cm
– Max. Pressure: 30mm 5.8 bars – 85 PSI / 35mm 5.1 bars – 74 PSI / 40mm 4.5 bars – 65 PSI
– Recommended tyre sizes: 28 to 62 mm (1.1´´ to 2.5´´)
Rims:
– ETRTO size: 622x23TC
– Height: 22 mm
– Internal width: 23 mm
– Joint: sleeved
– Disc brake specific profile
– Valve hole diameter: 6.5 mm
– Material: S6000 Aluminum
– Tyre: UST Tubeless and tubetype
Spokes:
– Nipples: steel, ABS
– Material: steel
– Lacing: front and rear crossed 2
– Count: 24 front and rear
– Shape: straight pull, round
Versions:
– Disc standard : 6 Bolts or Center Lock(R)
Delivered with:
– Rear QR adapters for Instant Drive 360
– Tubeless rim tape
– Front QR adapters
– UST valve and accessories
– User guide
KEY TECHNOLOGIES:
Instant Drive 360:
– The new Instant Drive 360 freewheel system is super light and fast to engage with only 9°. A large contactless rubber seal provides low friction, while a wide array of end caps makes it super versatile.
