Description

The EcoFlow Smart Meter provides precise, efficient, and connected energy monitoring for advanced energy management systems.
Featuring RS-485 communication and support for current transformers with 0.333 V output, it enables seamless integration with residential or commercial setups.
Its measurement range of 0.5 % to 120 % of nominal value ensures reliable readings even under variable conditions.
Designed for demanding environments, the Smart Meter operates between -25 °C and 55 °C with up to 95 % relative humidity.
Firmware and data updates via RS-485 (up to 115,200 bps and 1,000 m) guarantee long-term optimal performance.
Nominal voltage is 230 V L-N / 400 V L-L, with a voltage measurement range of 100-276 V and frequency support from 45-65 Hz.
Compact at 90 x 66 x 36 mm, weighing 115 g, and rated IP30, it offers Wi-Fi (802.11 b/g/n) up to 30 m indoors and Bluetooth 4.2 for up to 10 m.
With a designed lifespan of 10 years, a 2-year warranty, and extremely low field failure rates, EcoFlow Smart Meter ensures reliable, accurate, and versatile energy monitoring for resistive, capacitive, inductive, and bidirectional loads.
